MSI MAG Z790 TOMAHAWK WIFI Motherboard ATX - Supports Intel Core 14th/ 13th/ 12th Gen Processor, LGA 1700 Socket, 2.5Gbps LAN, 128GB DDR5 Max Memory

About

Description

Support Intel Core 14th/ 13th/ 12th Gen Processors, Intel Pentium, Gold and Celeron Processors for LGA 1700 socket.

Enhanced Power Design: 16+1+1 Mirrored Power Arrangement, dual 8-pin CPU power connectors, Core Boost, Memory Boost.

Premium Thermal Solution: Extended Heatsink Design and M.2 Shield Frozr are built for high performance system and non-stop works.

Lightning Fast Game experience: PCIe 5.0 slot, Lightning Gen 4 x4 M.2, USB 3.2 Gen 2x2.

High Quality PCB - 6-layer PCB made by 2oz thickened copper and server grade level material.

Audio Boost 5: Reward your ears with studio grade sound quality for the most immersive gaming experience.

💯 𝐅𝐑𝐄𝐄 𝐃𝐄𝐋𝐈𝐕𝐄𝐑𝐘 | 🚚 𝐐𝐔𝐈𝐂𝐊 𝐒𝐇𝐈𝐏 | ☎ 𝐆𝐑𝐄𝐀𝐓 𝐂𝐔𝐒𝐓𝐎𝐌𝐄𝐑'𝐒 𝐒𝐔𝐏𝐏𝐎𝐑𝐓

Characteristics

Brand MSI

Model number MAG Z790 TOMAHAWK WIFI

Chipset INTEL Z790

Form factor ATX (243.84mmx304.8mm)

Interface 2x PCI-E x16 slot, 1x PCl-E x1 slot

Storage 4 X M.2 Slot And 7x SATA 6G

Processor brand Intel

Processor model Intel Core Processors, Pentium Gold And Celeron Processors

Processor generation Support Intel Core 14th/ 13th/ 12th Gen Processors, Intel Pentium Gold And Celeron Processors

Memory type DDR5

Number of memory slots 4x DDR5 Memory Slots

Maximum memory Maximum 256GB

Wireless lan - bluetooth Wi-Fi 6E (Supports 802.11 a/ b/ g/ n/ ac/ ax) - Bluetooth 5.3 ( FIPS, FISMA)

Operating system Support For Windows 11 64-Bit / Windows 10 64-Bit

Lan Intel 2.5Gbps LAN

I/o ports 1x Power Connector(ATX_PWR), 2x Power Connector(CPU_PWR), 1x CPU Fan, 1x Pump Fan, 6x System Fan, 2x Front Panel (JFP), 1x Chassis Intrusion (JCI), 1x Front Audio (JAUD), 1x Tuning Controller connector(JDASH), 3x Addressable V2 RGB LED connector (JARGB_V2), 1x RGB LED connector(JRGB), 1x TPM pin header(Support TPM 2.0), 4x USB 2.0 ports, 2x USB 5Gbps Type A ports, 1x USB 10Gbps Type C ports

Audio ports Supports S/PDIF output / Supports up to 32-Bit/384 kHz playback on front panel

Video outputs 1x Display Port 1.4, 1x HDMI 2.1 Port

Usb ports Front - 4x USB 2.0, 2x USB 5Gbps Type A, 1x USB 10Gbps Type C, REAR - 4x USB 5Gbps Type A, 4x USB 10Gbps Type A, 1x USB 10Gbps Type C, 1x USB 20Gbps Type C

Weight 5.00 lb

Limited manufacturer warranty 2 Years

Description

Support Intel Core 14th/ 13th/ 12th Gen Processors, Intel Pentium, Gold and Celeron Processors for LGA 1700 socket.

Enhanced Power Design: 16+1+1 Mirrored Power Arrangement, dual 8-pin CPU power connectors, Core Boost, Memory Boost.

Premium Thermal Solution: Extended Heatsink Design and M.2 Shield Frozr are built for high performance system and non-stop works.

Lightning Fast Game experience: PCIe 5.0 slot, Lightning Gen 4 x4 M.2, USB 3.2 Gen 2x2.

High Quality PCB - 6-layer PCB made by 2oz thickened copper and server grade level material.

Audio Boost 5: Reward your ears with studio grade sound quality for the most immersive gaming experience.

💯 𝐅𝐑𝐄𝐄 𝐃𝐄𝐋𝐈𝐕𝐄𝐑𝐘 | 🚚 𝐐𝐔𝐈𝐂𝐊 𝐒𝐇𝐈𝐏 | ☎ 𝐆𝐑𝐄𝐀𝐓 𝐂𝐔𝐒𝐓𝐎𝐌𝐄𝐑'𝐒 𝐒𝐔𝐏𝐏𝐎𝐑𝐓

NEW

MSI MAG Z790 TOMAHAWK WIFI Motherboard ATX - Supports Intel Core 14th/ 13th/ 12th Gen Processor, LGA 1700 Socket, 2.5Gbps LAN, 128GB DDR5 Max Memory

Regular price: $339.99
Sale price: $339.99
Regular price: ~~$389.99~~
